310S/310H/310 Stainless Plate

Specification:ASTM A240 / ASME SA240

Item:301 Stainless Steel Plate(Hot rolled, cold rolled)

Standards:JIS, AISI, ASTM, GB, DIN, EN, etc

Range:1000/1219/1500/2000mm,etc

Surface:the surface and finish of 301 stainless steel plate: 2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, checkered, embossed, hair line, sand blast, Brush, etching, etc

Thickness:0.2 mm to 20mm

Width:1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc

Length:2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc

Hardness:Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc.

Material Grade:Stainless Steel 310 / 310S / 310H

  • Description
  • Specification
  • Standard
  • Process
  • Packing

310 Stainless Steel Sheet/Plate:

310 stainless steel sheet is an austenitic stainless steel developed for use in high temperature corrosion resistant applications. The alloy resists oxidation up to 2010℉ under mildly cyclic conditions.Because of its high chromium and moderate nickel content, Alloy 310 is resistant to sulfidation and can also be used in moderately carburizing atmospheres.

Grade 310 (UNS S31000) and its various subgrades combine excellent high temperature properties with good ductility and weldability.

310S Stainless Steel Sheet/Plate:

310S stainless steel sheet is the low carbon version of the alloy. It is utilized for ease of fabrication.

Grade 310S (UNS S31008) is used when the application environment involves moist corrodents in a temperature range lower than that which is normally considered "high temperature" service. The lower carbon content of 310S does reduce its high temperature strength compared to 310H.

310H Stainless Steel Sheet/Plate:

310H is a high carbon modification developed for enhanced creep resistance. In most instances the grain size and carbon content of the plate can meet both the 310S and 310H requirements

Grade 310H (UNS 531009) has a carbon content restricted to exclude the lower end of the 310 range, so is the grade of choice for high temperature applications.

Dimensions

ASTM, ASME and API

Standard

ASTM A240 / ASME SA240

Width

1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm,

Thickness

4mm-100mm

Length

2000mm, 2440mm, 3000mm, 5800mm, 6000mm,

Form

Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Perforated Sheet, Chequered Plate, Strip, Flats, Blank (Circle), Ring (Flange) etc.

Surface Finish

2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, chequered, embossed, hairline, sand blast, Brush, etching, Hot rolled plate (HR), Cold rolled sheet (CR), SATIN (Met with Plastic Coated) etc

Hardness

Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc

310

310S

310H

UNS S31000

UNS S31008

UNS S31009

ASTM A240

ASTM A240

ASTM A240

ASTM A480

ASTM A480

ASTM A480

ASME SA240

ASME SA240

ASME SA240

AMS 5521

AMS 5521

AMS 5521

Chemical Analysis

Element

310

310S

310H

Manganese

2.00

2.00

2.00

Nickel

19.0 min.-22.0 max.

19.0 min.-22.0 max.

19.0 min.-22.0 max.

Phosphorus

0.045

0.045

0.045

Carbon

0.25

0.08

0.40 min. – 0.10 max.

Chromium

24.0 min.-26.0 max.

24.0 min.-26.0 max.

24.0 min.-26.0 max.

Sulfur

0.030

0.030

0.030

Iron

Balance

Balance

Balance

Silicon

1.50

1.50

0.75

Phosphorus

0.045

0.045

0.045

Weight % (all values are maximum unless a range is otherwise indicated)

EQUIVALENT GRADES

STANDARD

WERKSTOFF NR.

UNS

JIS

BS

GOST

AFNOR

EN

SS 310

1.4841

S31000

SUS 310

310S24

20Ch25N20S2

-

X15CrNi25-20

SS 310S

1.4845

S31008

SUS 310S

310S16

20Ch23N18

-

X8CrNi25-21

SS 310H

-

S31009

-

-

-

-

-

MECHANICAL PROPERTIES

Density

Melting Point

Tensile Strength

Yield Strength (0.2%Offset)

Elongation

8.0 g/cm3

1400 °C (2550 °F)

Psi – 75000 , MPa – 515

Psi – 30000 , MPa – 205

35 %
