Aluminum Pipe Type |
Aluminum Pipe Grade/Schedule |
Aluminum Pip e Sizes |
Aluminum Seamless Pipe |
Alloys: 6061, 6063, 6101 |
OD: 0.75″ thru 12″ |
Aluminum Structural Pipe |
Alloys: 6061, 6063 |
OD: 0.375″ thru 8″ |
Product Name |
Aluminum Pipe / Tube |
Shape |
Round,Square,Rectangular or Customized |
Surface |
Mill finish, no stains, without rough selvedge,Anodizing |
Alloy |
1100/1050/1060/1070/1200/1350 |
3003/3004/3104/3005/3105 |
|
2014/2017A/2024/2A12/2219 |
|
5005/5049/5052/5083/8083/5182/5251/5454/5754 |
|
6061/6082/6063/6K61/6Z61 |
|
7049/7050/7072/7075 |
|
8011 |
|
Temper |
HO,H12,H14,H16,H18,H19,H22,H24,H26,H28,F,H112, T651,T3,T451,T4,T6,ect |
Process |
Hot rolled &Cold rolled |
Diameter |
3mm-1500mm |
Length |
Max 11000mm |
Package |
Export wooden pallents, craft paper, anti-blushing agent. |
Application |
Building,Boat,Truck,Tanker,Machine |
Quality of material |
Totally free frim defects like white rust, roll marks, efge damage, camber, denrs, holes, break lines, scratches and free from coil set. |
Non-Heat Treatable Alloys
3003 Drawn tube has excellent resistance to chemical attack and is a frequent choice in the manufacture and design of chemical equipment. Workability and weldability are excellent. Meets Federal specification WW-T-700/2 and ASTM B210. 3003-H14 drawn tube conforms to AMS 406
Heat Treatable Alloys
2011 extruded seamless tube for hollow screw machine parts. Where the machinability of 2011 is desired and the metal removal from solid bar stock is great, hollow 2011 screw machine stock can often be the most cost effective way to produce the part. Produced to ASTM B210.
2024 Drawn seamless tubing for superior strength tubular applications. 2024-T3 drawn tube conforms to Federal specifications WW-T-700/3, Type 1 as well as ASTM B210.
6061 Tubing and pipe, with approximately double the strength of 3003-H14, has widespread mechanical application. 6061 has good workability and corrosion resistance and is readily weldable by all methods. 6061-T6 drawn tube conforms to Federal specifications WW-T-700/6, ASTM B210 and AMS 4082. 6061-T6 extruded seamless tube conforms to AMS QQ-A-200/8, ASTM B221, and AMS 4150. 6061-T6 seamless pipe conforms to MIL-P-25995.
6063 Tubing and pipe is highly corrosion resistant with good workability and weldability. Finish is pleasing and is suitable for anodizing. Used primarily for architectural applications. (Drawn tube T832 used for furniture applications.) 6063-T832 drawn tube conforms to AMS QQ-A-200/9. 6063-T6 seamless pipe conforms to MIL-P-25995.
OM SIZE |
OUTSIDE |
WALL THICKNESS IN MM (T) |
METRIC SIZE |
||||||
SCH 10S |
SCH 10 |
SCH |
STD Weight |
SCH 40 |
SCH 80s |
SCH 80 |
|||
1/4 “ |
13.72 |
1.65 |
|
2.24 |
2.24 |
2.24 |
3.02 |
3.02 |
|
3/8″ |
17.15 |
1.65 |
|
2.31 |
2.31 |
2.31 |
3.2 |
3.2 |
|
1/2″ |
21.34 |
2.11 |
|
2.77 |
2.77 |
2.77 |
3.73 |
3.73 |
15 |
3/4″ |
26.67 |
2.11 |
|
2.87 |
2.87 |
2.87 |
3.91 |
3.91 |
20 |
1″ |
33.4 |
2.77 |
|
3.38 |
3.38 |
3.38 |
4.55 |
4.55 |
25 |
1 1/4″ |
42.16 |
2.77 |
|
3.56 |
3.56 |
3.56 |
4.85 |
4.85 |
32 |
1 1/2″ |
48.26 |
2.77 |
|
3.68 |
3.68 |
3.68 |
5.08 |
5.08 |
40 |
2″ |
60.32 |
2.77 |
|
3.91 |
3.91 |
3.91 |
5.54 |
5.54 |
50 |
2 1/2″ |
73.02 |
3.05 |
|
5.16 |
5.16 |
5.16 |
7.01 |
7.01 |
65 |
3″ |
88.9 |
3.05 |
|
5.49 |
5.49 |
5.49 |
7.62 |
7.62 |
80 |
3 1/2″ |
101.6 |
3.05 |
|
5.74 |
5.74 |
5.74 |
8.08 |
8.08 |
90 |
4″ |
114.3 |
3.05 |
|
6.02 |
6.02 |
6.02 |
8.56 |
8.56 |
100 |
5″ |
141.3 |
3.4 |
|
6.55 |
6.55 |
6.55 |
9.52 |
9.52 |
125 |
6″ |
168.27 |
3.4 |
|
7.11 |
7.11 |
7.11 |
10.97 |
10.97 |
150 |
8″ |
219.07 |
3.76 |
|
8.18 |
8.18 |
8.18 |
12.7 |
12.7 |
200 |
10″ |
273.05 |
4.19 |
|
9.27 |
9.27 |
9.27 |
12.7 |
15.08 |
250 |
12″ |
323.85 |
4.57 |
|
9.52 |
9.52 |
10.31 |
12.7 |
17.47 |
300 |
14″ |
355.6 |
4.77 |
6.35 |
|
9.52 |
11.12 |
|
19.05 |
350 |
16″ |
404.6 |
4.77 |
6.35 |
|
9.52 |
12.7 |
|
21.44 |
400 |
18″ |
457.2 |
4.77 |
6.35 |
|
9.52 |
14.27 |
|
23.82 |
450 |
ASTM B241 / ASME SB241 - Standard Specification for Aluminum and Aluminum-Alloy Seamless Pipe and Seamless Extruded Pipes
ASTM B345 / ASME S345 - Standard Specification for Aluminum and Aluminum-Alloy Seamless Pipe and Seamless Extruded Pipe for Gas and Oil Transmission and Distribution Piping Systems
ASTM B429 / ASME SB429 - Standard Specification for Aluminum-Alloy Extruded Structural Pipe and Tube
EN AW-AlMg1SiCu - Standard Specification for Aluminum and Aluminum-Alloy Round Pipe
ISO AlMg1SiCu - Standard Specification for Aluminum and Aluminum-Alloy Cold / Hot Rolled Piping
Chemical composition (%)
Alloy |
Si |
Fe |
Cu |
Mn |
Mg |
Cr |
Zn |
Ti |
Others |
Al |
1050 |
0.25 |
0.4 |
0.05 |
0.05 |
0.05 |
- |
0.05 |
0.03 |
0.15 |
99.5 |
1060 |
0.25 |
0.35 |
0.05 |
0.03 |
0.03 |
- |
0.03 |
0.03 |
0.15 |
99.6 |
1070 |
0.2 |
0.25 |
0.04 |
0.03 |
0.03 |
- |
0.04 |
0.03 |
0.15 |
99.7 |
1100 |
0.95 Si + Fe |
0.05-0.20 |
0.05 |
- |
- |
0.1 |
- |
0.15 |
99 |
|
2011 |
0.4 |
0.70 |
5.0-6.0 |
0.20-0.60 |
- |
0.3 |
- |
0.15 |
Remaining |
|
2014 |
0.5-1.2 |
0.5 |
3.9-5.0 |
0.4-1.2 |
0.2-0.8 |
0.1 |
0.25 |
0.15 |
0.15 |
Remaining |
2024 |
0.5 |
0.5 |
3.8-4.9 |
0.30-0.9 |
1.2-1.8 |
0.1 |
0.25 |
0.15 |
0.15 |
Remaining |
3003 |
0.6 |
0.7 |
0.05-0.20 |
1.0-1.5 |
- |
- |
0.1 |
- |
0.15 |
Remaining |
3004 |
0.3 |
0.7 |
0.25 |
1.0-1.5 |
0.8-1.3 |
- |
0.25 |
- |
0.15 |
Remaining |
3005 |
0.6 |
0.7 |
0.3 |
1.0-1.5 |
0.20-0.6 |
0.1 |
0.25 |
0.1 |
0.15 |
Remaining |
3105 |
0.6 |
0.7 |
0.3 |
0.3~0.8 |
0.2~0.8 |
0.2 |
0.4 |
0.1 |
0.15 |
Remaining |
5005 |
0.3 |
0.7 |
0.2 |
0.2 |
0.50-1.1 |
0.1 |
0.25 |
— |
0.15 |
Remaining |
5052 |
0.25 |
0.4 |
0.1 |
0.1 |
2.2-2.8 |
0.15-0.35 |
0.1 |
— |
0.15 |
Remaining |
5083 |
0.4 |
0.4 |
0.1 |
0.4-1.0 |
4.0~4.9 |
0.05~0.25 |
0.25 |
0.15 |
0.15 |
Remaining |
5252 |
0.08 |
0.1 |
0.1 |
0.1 |
2.2-2.8 |
— |
0.05 |
— |
0.1 |
Remaining |
5754 |
0.4 |
0.4 |
0.1 |
0.5 |
2.6~3.6 |
0.3 |
0.2 |
0.15 |
0.15 |
Remaining |
6061 |
0.40-0.8 |
0.7 |
0.15-0.40 |
0.15 |
0.8-1.2 |
0.04-0.35 |
0.25 |
0.15 |
0.15 |
Remaining |
7075 |
0.4 |
0.5 |
1.2-2.0 |
0.3 |
2.1-2.9 |
0.18-0.28 |
5.1-6.1 |
0.2 |
0.15 |
Remaining |
