Corten Steel Plate

Category : Steel Plate

Grade: Corten A & Corten B, A588, SA588, EN 10025-5, EN 10155, TB/T 1979, GB/T 4171, JIS G3114.

Specification (any size by request):

Thickness: 6-400 mm

Width: 1600-4200 mm

Length: 4000-15000mm

Material : Corten A, Corten B, S355J0WP, S355J0W, S355J2W, A588 Grade A, A588 Grade B, A588 Grade C, A242 Type 1, SA588 Grade A, SA588 Grade B, SA588 Grade C

Surface : Black painted, PE coated, Galvanized, color coated, anti rust varnished, anti rust oiled, checkered ,etc.

Package : Standard export package,suit for all kinds of transport,or as required.

Corten Steel Plate Available Finish:black painted,PE coated,Galvanized,color coated,anti rust varnished,anti rust oiled,checkered,etc

  • Description
  • Specification
  • Standard
  • Process
  • Packing

Corten is a weathering steel. This material is a corrosion resistant steel, that left uncoated develops an outer layer patina. This patina protects the steel from additional corrosion. It is a high strength steel alloy, and it is used where higher strength and longer life cycle material are desired. Especially in situations where untreated alloys are desired.

As CorTen became more popular over the years other producing mills began to develop their own atmospheric corrosion resistant weathering steels. ASTM stepped in and created what is considered equivalent specifications to Cor-Ten® in most applications.The applicable equivalent ASTM specifications are ASTM A588, A242, which Aakash Steel supplies in plate.

Features

(1)Weathering Resistance

Thanks to high weather resistance, corten steel can be used without painting. Unpainted applications are not only offer the economic advantage of reducing repainting costs; they also offer aesthetic benefits associated with the calming color of the protective rust

(2)Paint Durability

COR-TEN is paintable in the same way as ordinary steel. In addition, even if a painting defect should occur, COR-TEN suppresses the progress of rust area and prolongs the services life of paint, thereby reducing repainting costs.

(3)Weldability

While trace amounts of alloying elements such as copper (Cu) and chromate (Cr) are added to COR-TEN to ensure high weather resistance, the carbon content is lowered to provide appropriate  weldability. Accordingly, COR-TEN can be welded using either manual, gas-shield or submerged arc welding.

(4)Workability

COR-TEN possesses workability similar to ordinary steels of same strength.

All Sheets and Plates is manufactured and tested / inspected to the relevant standards including ASTM, ASME and API etc.

Corten Steel Gauge Width and Length

Weight Lbs. per Sq. Ft.

Estimated Weight per Sheet

7 ga. (.1874") x 48 x 120

7.871

314.8

10 ga. (.135") x 48 x 120

5.670

226.8

11 ga. (.120") x 36 x 120

5.040

151.2

11 ga. (.120") x 48 x 96

5.040

161.3

11 ga. (.120") x 48 x 120

5.040

201.6

11 ga. (.120") x 48 x 144

5.040

241.9

11 ga. (.120") x 60 x 96

5.040

252.0

12 ga. (.105") x 36 x 120

4.410

132.3

12 ga. (.105") x 48 x 120

4.410

176.4

12 ga. (.105") x 60 x 120

4.410

220.5

14 ga. (.075") x 36 x 120

3.150

94.50

14 ga. (.075") x 48 x 120

3.150

126.0

16 ga. (.060") x 36 x 120

2.520

75.60

16 ga. (.060") x 48 x 96

2.520

80.64

16 ga. (.060") x 48 x 120

2.520

100.8

16 ga. (.060") x 60 x 120

2.520

126.0

18 ga. (.048") x 36 x 120

2.016

60.48

18 ga. (.048") x 48 x 120

2.016

80.64

20 ga. (.036") x 36 x 120

1.512

45.36

20 ga. (.036") x 48 x 120

1.512

60.48

22 ga. (.030") x 36 x 120

1.260

37.80

22 ga. (.030") x 48 x 96

1.260

40.32

22 ga. (.030") x 48 x 120

1.260

50.40

24 ga. (.024") x 36 x 120

1.008

30.24

24 ga. (.024") x 48 x 120

1.008

40.32

26 ga. (.018") x 36 x 120

.7560

22.68

26 ga. (.018") x 48 x 120

.7560

30.24

28 ga. (.015") x 36 x 120

.6300

18.90

COR-TEN® A, COR-TEN®A, COR-TEN A, CORTEN-A, CORTEN A

S355J2W EN 10025-5, S355J2W EN10025-5, S355 J2W EN-10025-5

COR-TEN® B, COR-TEN®B, COR-TEN B, CORTEN-B, CORTEN B

S355J2W+N EN 10025-5, S355J2W+N EN10025-5, S355 J2W+N EN-10025-5

ASTM A588 Grade A, ASTM A 588 Grade-A, ASTM A-588 Grade A

S355J2G1W EN 10155, S355J2G1W EN10155, S355 J2G1W EN-10155

ASTM A588 Grade B, ASTM A 588 Grade-B, ASTM A-588 Grade B

S355K2G1W EN 10155, S355K2G1W EN10155, S355 K2G1W EN-10155

ASTM A588 Grade C, ASTM A 588 Grade-C, ASTM A-588 Grade C

S355J2G2W EN 10155, S355J2G2W EN10155, S355 J2G2W EN-10155

ASTM A242 Type 1, ASTM A242 Type-1, ASTM A-242 Type 1

S355K2G2W EN 10155, S355J2G2W EN10155, S355 K2G2W EN-10155

S355JOWP EN 10025-5, S355JOWP EN10025-5, S355 JOWP EN-10025-5

SAILCOR IRSM41, IRSM-41, IRS-M41 FOR RAILWAY WAGON & CONTAINER

S355JOWP+N EN 10025-5, S355JOWP+N EN10025-5, S355 JOWP+N EN-10025-5

JIS G3125 SPA-H, JIS G3125 SPAH, JIS:G3125-SPA-H, JIS-G3125-SPAH, G3125-SPA-H

Chemical Composition


According To

 C %
max.

 Si %
max.

 Mn %

 P %

 S %
max.

 N %
max.

 Cr %

 Cu %

V%

Ni%

Z%

Mo%

EN 10027-1
& CR 10260

























S235J0W

0.13

0.40

0.20-0.60

0.04

0.04

0.01

0.40-0.80

0.25-0.55

-

0.65

-

-

S235J2W

0.13

0.40

0.20-0.60

0.04

0.03

-

0.40-0.80

0.25-0.55

-

0.65

-

-

S355J0W

0.12

0.75

1.00

0.06-0.15

0.04

0.01

0.30-1.25

0.25-0.55

-

0.65

-

-

S355J2WP

0.12

0.75

1.00

0.06-0.15

0.03

-

0.30-1.25

0.25-0.55

-

0.65

-

-

S355J0W

0.16

0.50

0.50-1.50

0.04

0.04

0.01

0.40-0.80

0.25-0.55

-

0.65

0.15

0.30

S355J2W

0.16

0.50

0.50-1.50

0.03

0.03

-

0.40-0.80

0.25-0.55

-

0.65

0.15

0.30

S355K2W

0.16

0.50

0.50-1.50

0.03

0.03

-

0.40-0.80

0.25-0.55

-

0.65

0.15

0.30

According ToASTM &
ASME Specn.

A 588 Gr. A

0.19

0.3-
0.65

0.80-1.25

0.04

0.05

-

0.40-0.65

0.25-0.40

0.02-
0.10







A 588 Gr. B

0.20

0.15-
0.50

0.75-1.35

0.04

0.05

-

0.40-0.70

0.20-0.40

0.01-
0.10







A 588 Gr. C

0.15

0.15-
0.40

0.80-1.35

0.04

0.05

-

0.30-0.50

0.20-0.50

0.01-
0.10







A 588 Gr. K

0.17

0.25-
0.50

0.50-1.20

0.04

0.05

-

0.40-0.70

0.30-0.50

-



Cb-0.005
-0.05



A 242 Type-1

0.15

-

1.00

0.15

0.05





0.20 min.









A 242 Type-2

 0.20

1.50

0.04

0.05





0.20 min.









According ToIS STD.

IRSM-41

0.10

0.30-
0.50

0.25-0.45

0.075-0.14

0.03

-

0.35-0.49

0.30-0.60

0.05

0.28-
0.49

-

0.05


Equivalent Specifications of Corten Steel Plate/Sheet

Material #

EN 10155

SEW 087

NFA 35-502

UNI

BS 4360

ASTM

JIS G3114



1.8961

S235J2W

WTSt 37-3

E 24 W 4

Fe 360 DK 1

-

-

-

1.8945

S355J0WP

E 36 WA 3

Fe 510 C1K1

WR 50 A

-

-

-

1.8946

S355J2WP

-

E 36 WA 4

Fe 510 D1K1

-

A 242 Type 1

-

1.8959

S355J0W

-

E 36 WB 3

Fe 510 C2K1

WR 50 B

A 588 – A 242 Gr. 1

SMA 50 AW

1.8963

S355J2G1W

WTSt 52-3

-

Fe 510 D2K1

WR 50 C

A 588 Gr. A

to

1.8965

S355J2G2W

-

-

-

-

-

SMA 50 CP

1.8966

S355K2G1W

-

E 36 WB 4

-

-

A 709 Gr. 50 W

-

1.8967

S355K2G2W

-

-

-

-

-

-
